Aluminized
Aluminized steel can be subjected to moderate forming, spinning and drawing operations without coating peeling or flaking. It is suited for applications where high temperatures are encountered and can be welded by conventional methods.
Because of its attractive appearance, painting often isn't required. This product offers superior corrosion and oxidation protection at high temperatures and maintains its strength at temperatures up to 1200 degrees Fahrenheit. Aluminized steels can also be a cost effective alternative to stainless steel since they frequently maintain their appearance better in service than do 409-type stainless steels.
Primarily used for automotive applications, Usibor® is a group of aluminum-silicon coated press hardenable steels ranging from 1500 to 2000 MPa nominal tensile strengths. Usibor® enables customers to fabricate parts with complicated geometry at very high strength levels without formability or springback challenges. Typical applications include anti-intrusion and safety cage components, including bumper beams, door beams, rockers, pillars, roof rails and cross members. Combining Usibor® with Ductibor® 500 or Ductibor® 1000 into laser welded blanks offers several significant advantages, including weight savings, improved crash behavior and cost savings through material and manufacturing optimization.
We offer a wide range of precisely controlled chemical compositions with low residuals. Product attributes, additional offerings and capabilities include:
Surface finish
Exposed
For applications where final surface appearance is important, including for painted applications.
Surface treatments
Dry
No product is added after zinc coating. This is not recommended.Oil
Provides temporary corrosion protection and lubrication for forming operations.Prelube
Provides temporary corrosion protection and extra lubrication for forming operations.Chemical treated (hexavalent chromium)
Provides barrier corrosion protection.Chemical treated (RoHS compliant-trivalent chromium)
Provides barrier corrosion protection and complies with newer environmental standards requiring trivalent chromium.
Gauge | Width | Coating weights |
0.0182”-0.0944” | 36.25”-65” | T1-13, T1-20, T1-25, T1-40, T1-60 oz/ft2 or AS80 (40/40 g/m2), AS150 (70/70 g/m2) |
Size capability may vary by specification and facility. Please contact our sales department for specific information.
Agency spec or type | Grade |
ASTM A463 | Commercial steel type A, B, or C, Deep drawing steel (DDS), Extra deep drawing steel (EDDS) |
ASTM A463 | Structural steel grade 33, 37, 40 |
HSLA grades | SS gr33, 37, 40, 50, 55, 57, 80, 95 |
Bake hardenable steels | HSLA gr50 (345 MPa), HSLA gr60 (410 MPa) |
Press Hardenable Steels: Usibor® | 1500, 2000 |
Ductibor® | 500, 1000 |
This is a partial listing. Please inquire for other agency specs or OEM-specific grades.
